2016 Liv Invite geometry
Full frame geometry for the 2016 Liv Invite, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | BB drop (mm) | Front centre (mm) | Chainstay (mm) | Wheelbase (mm) | Fork rake (mm) | Trail (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| XS | 522 | 360 | 75 | 70 | 115 | 500 | 370 | 668 | 60 | 584 | 430 | 1007 | 50 | 74 |
| S | 538 | 366 | 74.5 | 70.5 | 130 | 515 | 420 | 704 | 60 | 591 | 430 | 1014 | 50 | 71 |
| M | 569 | 367 | 74.5 | 71 | 160 | 525 | 465 | 742 | 60 | 598 | 430 | 1021 | 50 | 68 |
| L | 597 | 380 | 74.5 | 71 | 190 | 545 | 500 | 773 | 60 | 620 | 430 | 1043 | 50 | 68 |
All measurements in millimetres unless marked (°) for angles.
