2016 Focus Jarifa Fat geometry
Full frame geometry for the 2016 Focus Jarifa Fat, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | BB drop (mm) | Front centre (mm) | Chainstay (mm) | Wheelbase (mm) | Fork rake (mm) | Trail (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| S | 622 | 395 | 74 | 70 | 100 | 574 | 420 | 70 | 645 | 472 | 1110 | 44 | 75 |
| M | 632 | 405 | 74 | 70 | 110 | 586 | 460 | 70 | 659 | 472 | 1123 | 44 | 75 |
| L | 651 | 420 | 74 | 70 | 130 | 607 | 500 | 70 | 680 | 472 | 1145 | 44 | 75 |
| XL | 670 | 430 | 74 | 70 | 150 | 623 | 540 | 70 | 697 | 472 | 1162 | 44 | 75 |
All measurements in millimetres unless marked (°) for angles.
