2023 Focus JAM2 SL geometry
Full frame geometry for the 2023 Focus JAM2 SL, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | BB drop (mm) | Chainstay (mm) | Wheelbase (mm) | Fork rake (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| M | 614 | 460 | 76.5 | 64.5 | 100 | 607 | 420 | 790 | 25 | 447 | 1230 | 44 |
| S | 614 | 430 | 76.5 | 64.5 | 100 | 578 | 390 | 790 | 25 | 447 | 1205 | 44 |
| L | 632 | 485 | 76.5 | 64.5 | 120 | 637 | 440 | 790 | 25 | 447 | 1264 | 44 |
| XL | 650 | 515 | 76.5 | 64.5 | 140 | 672 | 460 | 792 | 30 | 447 | 1297 | 44 |
All measurements in millimetres unless marked (°) for angles.
