2018 Focus Jam 27.5 C geometry
Full frame geometry for the 2018 Focus Jam 27.5 C, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | BB drop (mm) | Chainstay (mm) | Wheelbase (mm) | Fork rake (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| S | 586 | 410 | 74 | 66.3 | 110 | 574 | 410 | 12 | 425 | 1131 | 42 |
| M | 595 | 430 | 74 | 66.3 | 110 | 598 | 440 | 12 | 425 | 1156 | 42 |
| L | 620 | 450 | 74 | 66.3 | 135 | 623 | 470 | 12 | 425 | 1186 | 42 |
| XL | 637 | 470 | 74 | 66.3 | 155 | 648 | 500 | 12 | 425 | 1214 | 42 |
All measurements in millimetres unless marked (°) for angles.
