2026 Canyon Endurace CFR geometry
Full frame geometry for the 2026 Canyon Endurace CFR, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | BB drop (mm) | Chainstay (mm) | Wheelbase (mm) |
|---|---|---|---|---|---|---|---|---|---|---|
| 2XS | 499 | 375 | 76.6 | 69.5 | 88 | 515 | 432 | 73 | 413 | 985 |
| XS | 523 | 381 | 76.6 | 71 | 107 | 528 | 462 | 73 | 413 | 986 |
| S | 542 | 390 | 76.6 | 72.8 | 121 | 550 | 492 | 73 | 413 | 985 |
| M | 563 | 393 | 76.6 | 73.3 | 142 | 560 | 522 | 73 | 413 | 990 |
| L | 583 | 401 | 76.6 | 73.3 | 162 | 573 | 552 | 73 | 413 | 1003 |
| XL | 609 | 419 | 76.6 | 73.5 | 188 | 599 | 582 | 73 | 415 | 1029 |
All measurements in millimetres unless marked (°) for angles.
