2014 Canyon Endurace CF geometry
Full frame geometry for the 2014 Canyon Endurace CF, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | BB drop (mm) | Front centre (mm) | Chainstay (mm) | Wheelbase (mm) | Fork rake (mm) | Trail (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| XS/50 | 541 | 366 | 73.5 | 70.9 | 127 | 526 | 475 | 776 | 70 | 571 | 415 | 979 | 42 | 72 |
| S/53 | 556 | 373 | 73.5 | 71.6 | 143 | 538 | 510 | 802 | 70 | 576 | 415 | 987 | 42 | 67 |
| M/56 | 571 | 378 | 73.5 | 72.4 | 159 | 547 | 545 | 828 | 70 | 578 | 415 | 989 | 42 | 62 |
| L/58 | 590 | 380 | 73.5 | 73.3 | 175 | 555 | 565 | 848 | 70 | 578 | 415 | 989 | 42 | 57 |
| XL/60 | 610 | 395 | 73.5 | 73.3 | 196 | 576 | 595 | 873 | 70 | 599 | 415 | 1010 | 42 | 57 |
| 2XL/62 | 628 | 400 | 73.5 | 73.3 | 215 | 586 | 620 | 895 | 70 | 609 | 415 | 1020 | 42 | 57 |
| 3XL/65 | 646 | 417 | 73.5 | 73.3 | 234 | 608 | 645 | 918 | 70 | 632 | 415 | 1042 | 42 | 57 |
All measurements in millimetres unless marked (°) for angles.
