2026 Wilier Filante SLR ID2 geometry
Full frame geometry for the 2026 Wilier Filante SLR ID2, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Chainstay (mm) | Wheelbase (mm) |
|---|---|---|---|---|---|---|---|---|---|
| XS | 505 | 373.5 | 75.2 | 70.6 | 99 | 508 | 450 | 411 | 980.5 |
| S | 523 | 380 | 74.5 | 71.5 | 115 | 526 | 480 | 411 | 985.1 |
| M | 541 | 386.5 | 74 | 72 | 132 | 542 | 510 | 411 | 992.9 |
| L | 559 | 393 | 73.5 | 72.5 | 149 | 559 | 530 | 411 | 1000.4 |
| XL | 577 | 400 | 73 | 73 | 166 | 576 | 550 | 413 | 1010.1 |
| XXL | 595 | 408 | 73 | 73.5 | 183 | 590 | 570 | 413 | 1018.5 |
All measurements in millimetres unless marked (°) for angles.
