2017 Why R+ geometry
Full frame geometry for the 2017 Why R+, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | BB drop (mm) | Chainstay (mm) |
|---|---|---|---|---|---|---|---|---|---|---|
| S | 520 | 372 | 73 | 70 | 104 | 533 | 480 | 786 | 70 | 420 |
| M | 549 | 380 | 73 | 71.5 | 129 | 549 | 500 | 811 | 70 | 420 |
| L | 577 | 389 | 73 | 72 | 155 | 570 | 520 | 836 | 70 | 420 |
| XL | 602 | 400 | 73 | 72.5 | 181 | 584 | 540 | 858 | 70 | 420 |
All measurements in millimetres unless marked (°) for angles.
