2015 Stevens Trofeo geometry
Full frame geometry for the 2015 Stevens Trofeo, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | BB drop (mm) | Front centre (mm) | Chainstay (mm) | Wheelbase (mm) | Fork rake (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| XS | 511 | 387 | 77 | 71.5 | 110 | 505 | 480 | 721 | 72 | 586 | 395 | 970 | 45 |
| S | 532 | 407 | 77 | 72 | 130 | 530 | 520 | 756 | 72 | 608 | 395 | 992 | 45 |
| M | 552 | 427 | 77 | 72.5 | 150 | 555 | 550 | 799 | 72 | 630 | 395 | 1015 | 45 |
| L | 581 | 446 | 77 | 72.5 | 180 | 580 | 580 | 813 | 72 | 658 | 395 | 1042 | 45 |
All measurements in millimetres unless marked (°) for angles.
