2019 Stevens Super Trofeo geometry
Full frame geometry for the 2019 Stevens Super Trofeo, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | BB drop (mm) | Chainstay (mm) | Wheelbase (mm) | Fork rake (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| XS | 469 | 376 | 75 | 71 | 62 | 490 | 450 | 720 | 75 | 395 | 946 | 45 |
| S | 483 | 385 | 75 | 72.5 | 72 | 512 | 530 | 772 | 75 | 395 | 946 | 45 |
| M | 493 | 400 | 75 | 72.5 | 82 | 533 | 540 | 781 | 75 | 395 | 967 | 45 |
| L | 510 | 415 | 75 | 72.5 | 99 | 552 | 557 | 798 | 75 | 395 | 987 | 45 |
| XL | 528 | 428 | 75 | 72.5 | 118 | 570 | 576 | 816 | 75 | 395 | 1006 | 45 |
All measurements in millimetres unless marked (°) for angles.
