2019 Specialized Roubaix SL6 S-Works Team geometry
Full frame geometry for the 2019 Specialized Roubaix SL6 S-Works Team, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | BB drop (mm) | Front centre (mm) | Chainstay (mm) | Wheelbase (mm) | Fork rake (mm) | Trail (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 53 | 552 | 381 | 774 | 72.8 | 90 | 541 | 465 | 746 | 76 | 580 | 415 | 983 | 44 | 61 |
| 57 | 574 | 392 | 73.5 | 73.5 | 110 | 562 | 485 | 767 | 76 | 590 | 415 | 994 | 44 | 55 |
| 59 | 588 | 407 | 73.5 | 74 | 125 | 581 | 533 | 799 | 74 | 605 | 418 | 1012 | 44 | 52 |
All measurements in millimetres unless marked (°) for angles.
