2021 Specialized Diverge EVO geometry
Full frame geometry for the 2021 Specialized Diverge EVO, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | BB drop (mm) | Front centre (mm) | Chainstay (mm) | Wheelbase (mm) | Fork rake (mm) | Trail (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| S | 580 | 395 | 73.5 | 70 | 104 | 456 | 470 | 732 | 85 | 639 | 432 | 1057 | 55 | 69 |
| M | 607 | 420 | 73.5 | 70 | 133 | 600 | 500 | 754 | 85 | 674 | 432 | 1092 | 55 | 69 |
| L | 632 | 440 | 73.5 | 70 | 159 | 627 | 530 | 774 | 85 | 703 | 432 | 1121 | 55 | 69 |
All measurements in millimetres unless marked (°) for angles.
