2018 MMR Grip geometry
Full frame geometry for the 2018 MMR Grip, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | BB drop (mm) | Chainstay (mm) | Wheelbase (mm) | Fork rake (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| XS | 520 | 366 | 74 | 72 | 110 | 515 | 450 | 70 | 410 | 963 | 45 |
| S | 530 | 373 | 74 | 72 | 120 | 525 | 480 | 70 | 410 | 974 | 45 |
| M | 557 | 378 | 74 | 73 | 145 | 538 | 510 | 70 | 410 | 977 | 45 |
| L | 581 | 384 | 73 | 73.7 | 170 | 562 | 540 | 70 | 412 | 994 | 45 |
| XL | 602 | 391 | 73 | 73.5 | 190 | 575 | 570 | 70 | 412 | 994 | 45 |
| XXL | 621 | 398 | 73 | 73.5 | 210 | 588 | 600 | 70 | 412 | 994 | 45 |
All measurements in millimetres unless marked (°) for angles.
