2019 Laminar CX Tour geometry
Full frame geometry for the 2019 Laminar CX Tour, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | BB drop (mm) | Front centre (mm) | Chainstay (mm) | Wheelbase (mm) | Fork rake (mm) | Trail (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| XXS | 563 | 354 | 74.5 | 70.2 | 110 | 505 | 460 | 755 | 85 | 597 | 435 | 1018 | 50 | 73 |
| XS | 568 | 369 | 74.5 | 70.5 | 115 | 525 | 480 | 752 | 85 | 595 | 450 | 1033 | 50 | 71 |
| S | 586 | 370 | 72.5 | 70.8 | 135 | 545 | 500 | 769 | 82 | 601 | 450 | 1039 | 50 | 70 |
| M | 602 | 379 | 72.5 | 71.2 | 150 | 560 | 520 | 787 | 82 | 611 | 450 | 1049 | 50 | 66 |
| L | 614 | 388 | 72.2 | 71.2 | 165 | 575 | 540 | 804 | 80 | 624 | 450 | 1063 | 50 | 66 |
| XL | 633 | 396 | 72.2 | 71.2 | 185 | 590 | 560 | 823 | 80 | 639 | 450 | 1078 | 50 | 66 |
All measurements in millimetres unless marked (°) for angles.
