2023 Fara · G
2023 Fara F/Gravel geometry
Full frame geometry for the 2023 Fara F/Gravel, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Front centre (mm) | Chainstay (mm) | Wheelbase (mm) |
|---|---|---|---|---|---|---|---|---|---|
| 49 | 550 | 377 | 74 | 71 | 119 | 532 | 605 | 425 | 1017 |
| 53 | 570 | 386 | 73 | 71 | 138 | 559 | 618 | 425 | 1028 |
| 56 | 590 | 396 | 73 | 71 | 159 | 576 | 635 | 425 | 1043 |
| 59 | 610 | 407 | 73 | 71 | 180 | 593 | 653 | 425 | 1061 |
All measurements in millimetres unless marked (°) for angles.
