2019 Cube Town Hybrid geometry
Full frame geometry for the 2019 Cube Town Hybrid, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | BB drop (mm) | Front centre (mm) | Chainstay (mm) | Wheelbase (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 50 | 651 | 395 | 72 | 70 | 175 | 605 | 480 | 842 | 70 | 654 | 540 | 1186 |
| 54 | 665 | 402 | 72 | 70 | 190 | 617 | 520 | 870 | 70 | 666 | 540 | 1198 |
| 58 | 684 | 407 | 72 | 70 | 210 | 629 | 560 | 900 | 70 | 678 | 540 | 1210 |
| 62 | 702 | 413 | 72 | 70 | 230 | 641 | 600 | 930 | 70 | 690 | 540 | 1222 |
All measurements in millimetres unless marked (°) for angles.
