2014 Cube Ltd 27.5 geometry
Full frame geometry for the 2014 Cube Ltd 27.5, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | BB drop (mm) | Chainstay (mm) | Wheelbase (mm) |
|---|---|---|---|---|---|---|---|---|---|---|
| 16 | 587 | 382 | 73.5 | 69 | 100 | 556 | 405 | 52 | 420 | 1052 |
| 18 | 610 | 397 | 73.5 | 70 | 120 | 578 | 450 | 52 | 420 | 1064 |
| 20 | 629 | 413 | 73.5 | 70 | 140 | 599 | 490 | 52 | 420 | 1087 |
All measurements in millimetres unless marked (°) for angles.
