2014 Cube Elite C68 29 geometry
Full frame geometry for the 2014 Cube Elite C68 29, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | BB drop (mm) | Chainstay (mm) | Wheelbase (mm) |
|---|---|---|---|---|---|---|---|---|---|---|
| 15 | 609 | 390 | 73 | 70 | 95 | 575 | 370 | 65 | 435 | 1073 |
| 17 | 613 | 409 | 73 | 70 | 100 | 595 | 420 | 65 | 435 | 1093 |
| 19 | 625 | 428 | 73 | 70.5 | 110 | 618 | 470 | 65 | 435 | 1111 |
| 21 | 634 | 444 | 73 | 70.5 | 120 | 637 | 515 | 65 | 435 | 1130 |
| 23 | 648 | 451 | 73 | 70.5 | 135 | 648 | 565 | 65 | 435 | 1141 |
All measurements in millimetres unless marked (°) for angles.
