2005 Cervelo P2T geometry
Full frame geometry for the 2005 Cervelo P2T, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Top tube (mm) | Standover (mm) | BB drop (mm) | Front centre (mm) | Chainstay (mm) | Wheelbase (mm) |
|---|---|---|---|---|---|---|---|---|---|---|
| S | 473 | 411 | 74 | 73 | 548 | 758 | 50 | 588 | 368 | 950 |
| M | 483 | 434 | 74 | 73 | 573 | 767 | 50 | 613 | 368 | 976 |
| L | 502 | 453 | 74 | 73 | 597 | 787 | 50 | 638 | 368 | 1001 |
All measurements in millimetres unless marked (°) for angles.
