2019 Canyon Ultimate CF Evo Disc geometry
Full frame geometry for the 2019 Canyon Ultimate CF Evo Disc, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | BB drop (mm) | Front centre (mm) | Chainstay (mm) | Wheelbase (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 2XS | 500 | 368 | 73.8 | 69.6 | 89 | 513 | 434 | 735 | 72 | 571 | 415 | 975 |
| XS | 522 | 378 | 73.8 | 71 | 107 | 530 | 467 | 762 | 72 | 576 | 415 | 980 |
| S | 546 | 385 | 73.8 | 72.2 | 130 | 544 | 494 | 790 | 70 | 580 | 415 | 985 |
| M | 567 | 391 | 73.8 | 73.2 | 148 | 556 | 522 | 816 | 70 | 583 | 415 | 988 |
| L | 592 | 399 | 73.8 | 73.2 | 174 | 571 | 554 | 844 | 70 | 598 | 415 | 1003 |
| XL | 613 | 418 | 73.8 | 73.5 | 195 | 596 | 584 | 870 | 70 | 621 | 415 | 1026 |
| 2XL | 631 | 428 | 73.8 | 73.5 | 213 | 611 | 614 | 895 | 70 | 634 | 415 | 1039 |
All measurements in millimetres unless marked (°) for angles.
