2017 Canyon Stitched 720 geometry
Full frame geometry for the 2017 Canyon Stitched 720, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | BB drop (mm) | Chainstay (mm) | Wheelbase (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| M | 556 | 430 | 72.5 | 69 | 118 | 527 | 326 | 767 | 10 | 397 | 1081 |
All measurements in millimetres unless marked (°) for angles.
