2015 Canyon Spectral AL 29 geometry
Full frame geometry for the 2015 Canyon Spectral AL 29, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | BB drop (mm) | Chainstay (mm) | Wheelbase (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| S | 605 | 401 | 74 | 68.5 | 100 | 574 | 395 | 798 | 33 | 445 | 1119 |
| M | 614 | 419 | 74 | 68.5 | 110 | 595 | 440 | 802 | 33 | 445 | 1140 |
| L | 628 | 439 | 74 | 68.5 | 125 | 619 | 485 | 814 | 33 | 445 | 1166 |
| XL | 656 | 459 | 74 | 68.5 | 155 | 647 | 545 | 847 | 33 | 445 | 1197 |
All measurements in millimetres unless marked (°) for angles.
