2010 Aerocat R350 geometry
Full frame geometry for the 2010 Aerocat R350, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | BB drop (mm) | Front centre (mm) | Chainstay (mm) | Wheelbase (mm) | Fork rake (mm) | Trail (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 48 | 510 | 372 | 74.3 | 71.2 | 110 | 515 | 480 | 703 | 68 | 573 | 410 | 973 | 43 | 68 |
| 50 | 515 | 382 | 74.3 | 71.2 | 115 | 527 | 500 | 722 | 68 | 585 | 410 | 985 | 43 | 68 |
| 52 | 534 | 380 | 74.3 | 71.2 | 135 | 530 | 520 | 740 | 68 | 589 | 410 | 989 | 43 | 68 |
| 54 | 548 | 391 | 74.3 | 71.2 | 150 | 545 | 540 | 758 | 68 | 605 | 410 | 1005 | 43 | 68 |
| 56 | 567 | 411 | 74.3 | 71.2 | 170 | 570 | 560 | 775 | 68 | 630 | 410 | 1031 | 43 | 68 |
| 58 | 586 | 417 | 74.3 | 71.2 | 190 | 582 | 580 | 795 | 68 | 643 | 410 | 1044 | 43 | 68 |
| 60 | 605 | 418 | 74.3 | 71.2 | 210 | 588 | 600 | 814 | 68 | 650 | 410 | 1051 | 43 | 68 |
All measurements in millimetres unless marked (°) for angles.
