2010 Serotta Stock Road geometry

Name: 2010 Serotta Stock Road
Brand: Serotta

Full frame geometry for the 2010 Serotta Stock Road, size by size — stack, reach, angles and tube lengths.

Does this bike fit you? Get sized in minutes — no tape measure, no appointment.

Geometry by size

Size	Stack (mm)	Reach (mm)	Seat angle (°)	Head angle (°)	Head tube (mm)	Top tube (mm)	Seat tube (mm)	Standover (mm)	BB drop (mm)	Front centre (mm)	Chainstay (mm)	Wheelbase (mm)	Fork rake (mm)	Trail (mm)
46P	496	352	75	71	142	485	460	708	53	542	405	941	34	71
48P	505	350	74	71	152	495	480	722	53	544	405	943	34	71
48	510	368	75	71.5	100	505	480	723	80	562	415	963	45	64
50	527	369	74.5	71.5	118	515	500	741	80	568	415	970	45	64
52	544	369	74	72	135	525	520	759	80	569	418	973	45	61
52S	544	349	74	72	135	505	520	759	80	549	418	953	45	61
54	560	369	73.5	72	151	535	540	776	80	575	418	979	45	61
54S	560	359	73.5	72	151	525	540	776	80	565	418	969	45	61
56	578	373	73	73	167	550	560	796	80	575	420	981	45	55
58	601	381	73	73	191	565	580	815	80	590	420	996	45	55
60	620	390	73	73	216	580	600	840	75	606	425	1020	45	55
62	638	400	73	73	234	595	620	860	75	621	425	1035	45	55

All measurements in millimetres unless marked (°) for angles.
