2022 Serk A30 geometry
Full frame geometry for the 2022 Serk A30, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Chainstay (mm) | Wheelbase (mm) | Fork rake (mm) | Trail (mm) |
|---|---|---|---|---|---|---|---|---|---|---|
| XS | 506 | 365 | 74.5 | 70.5 | 95 | 506 | 418 | 984 | 50 | 67.7 |
| S | 529 | 374 | 74 | 72 | 111 | 526 | 418 | 979 | 43 | 65.6 |
| M | 552 | 382 | 73.5 | 72.5 | 134 | 545 | 418 | 990 | 43 | 62.4 |
| L | 575 | 390 | 73 | 73 | 156 | 567 | 418 | 1000 | 43 | 59.3 |
| XL | 598 | 398 | 72.5 | 73.5 | 178 | 587 | 418 | 1010 | 43 | 56.2 |
All measurements in millimetres unless marked (°) for angles.
