2016 Orbea Occam AM H geometry
Full frame geometry for the 2016 Orbea Occam AM H, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | BB drop (mm) | Front centre (mm) | Chainstay (mm) | Wheelbase (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| S (27.5) | 585 | 406 | 75 | 67 | 110 | 563 | 393 | 713 | 15 | 696 | 425 | 1121 |
| M (27.5) | 595 | 431 | 75 | 67 | 120 | 590 | 432 | 741 | 15 | 724 | 425 | 1149 |
| L (27.5) | 604 | 450 | 75 | 67 | 130 | 612 | 470 | 768 | 15 | 748 | 425 | 1173 |
All measurements in millimetres unless marked (°) for angles.
