2015 Niner ROS 9 geometry
Full frame geometry for the 2015 Niner ROS 9, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | BB drop (mm) | Front centre (mm) | Chainstay (mm) | Wheelbase (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| S-140 | 632 | 386 | 73 | 67 | 100 | 581 | 394 | 712 | 49 | 683 | 427 | 1105 |
| S-120 | 634 | 396 | 74 | 68 | 100 | 578 | 394 | 709 | 56 | 677 | 427 | 1098 |
| M-140 | 641 | 400 | 73 | 67 | 110 | 598 | 431 | 733 | 49 | 701 | 427 | 1123 |
| M-120 | 643 | 411 | 74 | 68 | 110 | 595 | 431 | 730 | 56 | 695 | 427 | 1116 |
| L-140 | 655 | 415 | 73 | 67 | 125 | 617 | 471 | 787 | 49 | 722 | 427 | 1144 |
| L-120 | 657 | 426 | 74 | 68 | 125 | 614 | 471 | 783 | 56 | 716 | 427 | 1136 |
| XL-140 | 674 | 428 | 73 | 67 | 145 | 636 | 534 | 839 | 49 | 743 | 427 | 1165 |
| XL-120 | 675 | 439 | 74 | 68 | 145 | 633 | 534 | 833 | 56 | 737 | 427 | 1158 |
All measurements in millimetres unless marked (°) for angles.
