2025 Niner ORE 9 RDO geometry
Full frame geometry for the 2025 Niner ORE 9 RDO, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Standover (mm) | BB drop (mm) | Chainstay (mm) | Wheelbase (mm) | Fork rake (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 47 | 545 | 369 | 74 | 69 | 90 | 495 | 693 | 70 | 435 | 1034 | 50 |
| 50 | 560 | 395 | 74 | 69 | 106 | 520 | 731 | 70 | 435 | 1066 | 50 |
| 53 | 579 | 405 | 74 | 69 | 126 | 535 | 754 | 70 | 435 | 1083 | 50 |
| 56 | 598 | 413 | 73 | 69 | 146 | 545 | 780 | 70 | 435 | 1099 | 50 |
| 59 | 617 | 422 | 73 | 69 | 167 | 560 | 804 | 70 | 435 | 1115 | 50 |
| 62 | 636 | 441 | 73 | 69 | 188 | 585 | 827 | 70 | 435 | 1142 | 50 |
All measurements in millimetres unless marked (°) for angles.
