2018 MMR Woki 27.5 geometry
Full frame geometry for the 2018 MMR Woki 27.5, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | BB drop (mm) | Chainstay (mm) | Wheelbase (mm) | Fork rake (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| S | 598 | 374 | 73 | 70.5 | 115 | 557 | 406 | 45 | 435 | 1047 | 42 |
| M | 613 | 389 | 73 | 70.5 | 130 | 576 | 457 | 45 | 435 | 1067 | 42 |
All measurements in millimetres unless marked (°) for angles.
