2026 InColor Voyager geometry
Full frame geometry for the 2026 InColor Voyager, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Standover (mm) | BB drop (mm) | Front centre (mm) | Chainstay (mm) | Wheelbase (mm) | Fork rake (mm) | Trail (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 45 | 515 | 358 | 75 | 70 | 109 | 496 | 735 | 74 | 580 | 415 | 984 | 53.7 | 70.3 |
| 48 | 526 | 366 | 74.5 | 70.5 | 119 | 512 | 748.5 | 74 | 588 | 415 | 991 | 53.7 | 67 |
| 51 | 539 | 375 | 74 | 71 | 129 | 530 | 762 | 74 | 592 | 415 | 996 | 49.7 | 67.9 |
| 54 | 555 | 385 | 74 | 71.5 | 144 | 544 | 781 | 74 | 603 | 415 | 1007 | 49.7 | 64.7 |
| 57 | 580 | 397 | 73.5 | 72 | 168 | 569 | 806 | 74 | 618 | 415 | 1022 | 49.7 | 61.4 |
All measurements in millimetres unless marked (°) for angles.
