2018 Fairdale · R
2018 Fairdale Goodship geometry
Full frame geometry for the 2018 Fairdale Goodship, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | BB drop (mm) | Front centre (mm) | Chainstay (mm) | Wheelbase (mm) | Fork rake (mm) | Trail (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 52 | 540 | 382 | 74 | 73 | 135 | 537 | 490 | 754 | 72 | 577 | 408 | 974 | 45 | 57 |
| 54 | 552 | 384 | 73.5 | 73 | 150 | 548 | 510 | 772 | 70 | 583 | 408 | 981 | 45 | 57 |
| 56 | 574 | 390 | 73 | 73.5 | 170 | 565 | 530 | 791 | 70 | 588 | 408 | 986 | 45 | 53 |
| 58 | 593 | 399 | 73 | 73.5 | 190 | 580 | 550 | 810 | 70 | 602 | 408 | 1000 | 45 | 53 |
| 60 | 610 | 399 | 73 | 73.5 | 210 | 585 | 570 | 831 | 68 | 607 | 410 | 1008 | 45 | 53 |
All measurements in millimetres unless marked (°) for angles.
