2025 Enigma · G
2025 Enigma Esker geometry
Full frame geometry for the 2025 Enigma Esker, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | BB drop (mm) | Chainstay (mm) | Wheelbase (mm) | Fork rake (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 50 | 534 | 364 | 76 | 70.5 | 95 | 500 | 460 | 75 | 435 | 1008 | 50 |
| 51 | 544 | 366 | 75.5 | 70.5 | 105 | 510 | 475 | 75 | 435 | 1009 | 50 |
| 52 | 553 | 369 | 75 | 70.5 | 115 | 520 | 490 | 75 | 435 | 1020 | 50 |
| 53 | 564 | 371 | 74.5 | 71 | 125 | 530 | 505 | 75 | 435 | 1021 | 50 |
| 54 | 573 | 374 | 74 | 71 | 135 | 540 | 520 | 75 | 435 | 1027 | 50 |
| 55 | 583 | 381 | 74 | 71 | 145 | 550 | 535 | 75 | 435 | 1037 | 50 |
| 56 | 595 | 388 | 74 | 71.5 | 155 | 560 | 550 | 75 | 435 | 1043 | 50 |
| 57 | 604 | 390 | 73.5 | 71.5 | 165 | 570 | 565 | 75 | 435 | 1048 | 50 |
| 58 | 614 | 391 | 73 | 71.5 | 175 | 580 | 580 | 75 | 435 | 1053 | 50 |
| 59 | 625 | 398 | 73 | 72 | 185 | 590 | 595 | 75 | 435 | 1058 | 50 |
| 60 | 635 | 405 | 73 | 72 | 195 | 600 | 610 | 75 | 435 | 1068 | 50 |
All measurements in millimetres unless marked (°) for angles.
