2026 Curve CarboKev geometry
Full frame geometry for the 2026 Curve CarboKev, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | BB drop (mm) | Front centre (mm) | Chainstay (mm) | Wheelbase (mm) | Fork rake (mm) | Trail (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| XXS | 550 | 365 | 74 | 70 | 105 | 523 | 460 | 735 | 78 | 597 | 436 | 1021 | 52 | 78 |
| XS | 555 | 376 | 74 | 70 | 110 | 535 | 500 | 762 | 78 | 610 | 436 | 1034 | 52 | 78 |
| SM | 564 | 384 | 74 | 70 | 120 | 546 | 530 | 785 | 78 | 621 | 436 | 1046 | 52 | 78 |
| MD | 576 | 388 | 73.5 | 70 | 132 | 559 | 550 | 814 | 78 | 629 | 439 | 1057 | 52 | 78 |
| LG | 588 | 393 | 73 | 70 | 148 | 573 | 570 | 826 | 75 | 639 | 439 | 1067 | 52 | 78 |
| XL | 607 | 402 | 73 | 70 | 168 | 588 | 585 | 842 | 75 | 655 | 442 | 1087 | 52 | 78 |
| XXL | 646 | 405 | 73 | 70 | 210 | 602 | 605 | 870 | 75 | 672 | 442 | 1104 | 52 | 78 |
All measurements in millimetres unless marked (°) for angles.
