2017 AX-Lightness Vial Evo XC geometry
Full frame geometry for the 2017 AX-Lightness Vial Evo XC, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | BB drop (mm) | Chainstay (mm) |
|---|---|---|---|---|---|---|---|---|---|
| M/44 | 595 | 420 | 73.5 | 68.5 | 95 | 597 | 440 | 60 | 427 |
| L/48 | 605 | 443 | 73.5 | 68.5 | 105 | 622 | 480 | 60 | 427 |
All measurements in millimetres unless marked (°) for angles.
