2026 Marin DSX FS geometry
Full frame geometry for the 2026 Marin DSX FS, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | BB drop (mm) | Chainstay (mm) | Wheelbase (mm) | Fork rake (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| S | 583.2 | 400 | 74 | 68.5 | 100 | 567.2 | 430 | 667 | 82 | 425 | 1065 | 47 |
| M | 601.8 | 425 | 74 | 68.5 | 120 | 597.6 | 480 | 708 | 82 | 425 | 1097.3 | 47 |
| L | 629.7 | 440 | 74 | 68.5 | 150 | 620.6 | 520 | 738 | 82 | 425 | 1123.3 | 47 |
| XL | 657.6 | 455 | 74 | 68.5 | 180 | 643.6 | 558 | 741.7 | 82 | 425 | 1149.3 | 47 |
All measurements in millimetres unless marked (°) for angles.
