2022 Malvern Star Forager geometry
Full frame geometry for the 2022 Malvern Star Forager, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Top tube (mm) | BB drop (mm) | Chainstay (mm) |
|---|---|---|---|---|---|---|---|
| S | 622 | 420 | 77 | 68 | 590.6 | 63.5 | 442 |
| M | 630 | 449 | 76.5 | 68 | 622.3 | 63.5 | 442 |
| L | 639 | 472 | 76.3 | 68 | 647.7 | 63.5 | 442 |
| XL | 650 | 506 | 75.5 | 68 | 685.8 | 63.5 | 442 |
All measurements in millimetres unless marked (°) for angles.
