2026 ICAN Graro geometry
Full frame geometry for the 2026 ICAN Graro, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | BB drop (mm) | Front centre (mm) | Chainstay (mm) | Wheelbase (mm) | Fork rake (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 46 | 505 | 365 | 74.5 | 70 | 79 | 505 | 460 | 71 | 580 | 425 | 995 | 50 |
| 49 | 519 | 374 | 74.5 | 70 | 94 | 518 | 475 | 71 | 595 | 425 | 1009 | 50 |
| 52 | 544 | 378 | 74 | 70 | 121 | 534.5 | 490 | 71 | 608 | 425 | 1023 | 50 |
| 54 | 565 | 387 | 73.5 | 71 | 139 | 554.5 | 505 | 71 | 614 | 425 | 1029 | 50 |
| 56 | 590 | 398 | 73 | 71 | 165 | 578.5 | 523 | 71 | 634 | 425 | 1049 | 50 |
| 58 | 610 | 406 | 73 | 71 | 186 | 592.5 | 543 | 71 | 648 | 425 | 1064 | 50 |
All measurements in millimetres unless marked (°) for angles.
