2023 Bross Zenith geometry
Full frame geometry for the 2023 Bross Zenith, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | BB drop (mm) | Wheelbase (mm) | Fork rake (mm) | Trail (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| XS(49) | 538.5 | 368.3 | 75 | 71 | 142.4 | 512.6 | 455 | 755.5 | 70 | 986.5 | 50 | 66.6 |
| S(52) | 564.8 | 389.5 | 74 | 73 | 160.2 | 551.5 | 496 | 788.6 | 70 | 991.8 | 45 | 59 |
| M(55) | 576.7 | 398.9 | 74 | 73 | 172.6 | 564.3 | 526 | 809.1 | 70 | 1004.9 | 45 | 59 |
| L(58) | 590.5 | 402.1 | 73 | 73.5 | 185.2 | 577 | 539 | 822.8 | 70 | 1007.2 | 45 | 55.9 |
| XL(61 | 614.4 | 419.6 | 73.5 | 73.5 | 210.1 | 601.6 | 565 | 846.8 | 70 | 1031 | 45 | 55.9 |
All measurements in millimetres unless marked (°) for angles.
