2019 Trek Police MKII geometry
Full frame geometry for the 2019 Trek Police MKII, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | BB drop (mm) | Front centre (mm) | Chainstay (mm) | Wheelbase (mm) | Fork rake (mm) | Trail (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| M | 602 | 418 | 73 | 69.5 | 90 | 602 | 419 | 748 | 58 | 668 | 438 | 1100 | 42 | 93 |
| S | 602 | 389 | 73.5 | 69.5 | 90 | 567 | 368 | 741 | 58 | 639 | 438 | 1071 | 42 | 93 |
| L | 611 | 451 | 73 | 69.5 | 100 | 638 | 470 | 757 | 58 | 705 | 438 | 1137 | 42 | 93 |
| XL | 630 | 466 | 73 | 69.5 | 120 | 659 | 521 | 769 | 58 | 727 | 438 | 1159 | 42 | 93 |
| XXL | 630 | 480 | 73 | 69.5 | 120 | 673 | 559 | 804 | 58 | 741 | 438 | 1173 | 42 | 93 |
All measurements in millimetres unless marked (°) for angles.
