2008 Trek Equinox Al Alpha Black geometry
Full frame geometry for the 2008 Trek Equinox Al Alpha Black, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | BB drop (mm) | Front centre (mm) | Chainstay (mm) | Wheelbase (mm) | Fork rake (mm) | Trail (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 54 | 506 | 411 | 76 | 73 | 104 | 537 | 540 | 747 | 68 | 594 | 405 | 989 | 45 | 56 |
| 50 | 523 | 372 | 76 | 72.5 | 122 | 502 | 500 | 734 | 68 | 559 | 385 | 943 | 40 | 56 |
| 56 | 523 | 417 | 76 | 73 | 122 | 547 | 560 | 792 | 68 | 605 | 405 | 1000 | 45 | 56 |
| 52 | 539 | 388 | 76 | 72.5 | 139 | 522 | 520 | 753 | 68 | 580 | 385 | 964 | 40 | 56 |
| 58 | 539 | 428 | 76 | 73 | 139 | 562 | 580 | 806 | 68 | 621 | 405 | 1010 | 45 | 56 |
| 60 | 558 | 443 | 76 | 73 | 159 | 582 | 600 | 826 | 68 | 642 | 405 | 1030 | 45 | 56 |
All measurements in millimetres unless marked (°) for angles.
