2019 Trek Dual Sport + Womens geometry
Full frame geometry for the 2019 Trek Dual Sport + Womens, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | BB drop (mm) | Chainstay (mm) | Wheelbase (mm) | Fork rake (mm) | Trail (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| XS | 593 | 385 | 74.5 | 70 | 115 | 550 | 330 | 694 | 60 | 455 | 1070 | 38 | 89 |
| S | 595 | 390 | 74 | 70.5 | 115 | 560 | 381 | 716 | 60 | 455 | 1070 | 38 | 85 |
| M | 606 | 395 | 73.5 | 71 | 125 | 575 | 445 | 745 | 60 | 455 | 1075 | 38 | 82 |
All measurements in millimetres unless marked (°) for angles.
