2015 Trek 920 geometry
Full frame geometry for the 2015 Trek 920, size by size — stack, reach, angles and tube lengths.
Does this bike fit you?
Get sized in minutes — no tape measure, no appointment.
Geometry by size
| Size | Stack (mm) | Reach (mm) | Seat angle (°) | Head angle (°) | Head tube (mm) | Top tube (mm) | Seat tube (mm) | Standover (mm) | BB drop (mm) | Chainstay (mm) | Wheelbase (mm) | Fork rake (mm) | Trail (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 49 | 556 | 385 | 74.5 | 70 | 95 | 540 | 440 | 722 | 85 | 465 | 1072 | 55 | 75 |
| 52 | 567 | 388 | 74 | 70.5 | 105 | 551 | 470 | 743 | 85 | 465 | 1074 | 55 | 72 |
| 54 | 583 | 392 | 73.8 | 71 | 120 | 562 | 490 | 760 | 85 | 465 | 1079 | 55 | 68 |
| 56 | 608 | 395 | 73.3 | 71.3 | 145 | 578 | 510 | 778 | 85 | 465 | 1088 | 55 | 67 |
| 58 | 627 | 402 | 73 | 71.3 | 165 | 594 | 530 | 796 | 85 | 465 | 1100 | 55 | 67 |
| 61 | 642 | 405 | 72.8 | 71.5 | 180 | 604 | 560 | 817 | 85 | 465 | 1107 | 55 | 65 |
All measurements in millimetres unless marked (°) for angles.
